What is OSI model (Open up Systems Interconnection)?

OSI (Open Systems Interconnection) is a reference model for how applications communicate over a network. This model focuses on providing a visual design of how each communications layer is congenital on meridian of the other, starting with the physical cabling, all the mode to the application that's trying to communicate with other devices on a network.

A reference model is a conceptual framework for understanding relationships. The purpose of the OSI reference model is to guide technology vendors and developers so the digital communications products and software programs they create tin can interoperate and to promote a articulate framework that describes the functions of a networking or telecommunication system that's in apply.

About vendors involved in telecommunications try to draw their products and services in relation to the OSI model. This helps them differentiate among the various transport protocols, addressing schemes and communications packaging methods. And, although it'due south useful for guiding discussion and evaluation, the OSI model is theoretical in nature and should be used but as a general guide. That's considering few network products or standard tools go along related functions together in well-defined layers, as is the case in the OSI model. The Transmission Control Protocol/Net Protocol (TCP/IP) suite, for case, is the nearly widely used network protocol, but even information technology doesn't map cleanly to the OSI model.

History of the OSI model

In the 1970s, applied science researchers began examining how computer systems could best communicate with each other. Over the adjacent few years, several competing models were created and published to the customs. However, it wasn't until 1984 when the International System for Standardization (ISO) took the best parts of competing networking reference models to propose OSI every bit a mode to finally create a framework that technology companies around the world could utilise as the basis of their networking technologies.

From ISO's perspective, the easiest way to create a conceptual model was to organize the models into different brainchild layers required to organize and send data between computing systems. Looking inside each abstracted layer to see the details shows ane part of this network advice process. Each layer can be thought of every bit a separate advice module or slice of the puzzle. Simply, to really accomplish the goal of sending data from one device to another, each module must piece of work together.

How the OSI model works

Information technology (Information technology) networking professionals utilise OSI to model or conceptualize how data is sent or received over a network. Understanding this is a foundational part of most It networking certifications, including the Cisco Certified Network Associate (CCNA) and CompTIA Network+ certification programs. As mentioned, the model is designed to break down data manual standards, processes and protocols over a series of seven layers, each of which is responsible for performing specific tasks concerning sending and receiving data.

The principal concept of OSI is that the process of communication between two endpoints in a network can be divided into seven distinct groups of related functions, or layers. Each communicating user or programme is on a device that tin provide those vii layers of function.

In this architecture, each layer serves the layer in a higher place it and, in turn, is served by the layer beneath it. So, in a given message between users, there will exist a flow of information down through the layers in the source computer, across the network and then up through the layers in the receiving calculator. Only the application layer at the top of the stack doesn't provide services to a higher-level layer.

The seven layers of function are provided by a combination of applications, operating systems (OSes), network carte device drivers, networking hardware and protocols that enable a organization to transmit a signal over a network through various physical mediums, including twisted-pair copper, fiber eyes, Wi-Fi or Long-Term Evolution (LTE) with 5G.

vii layers of the OSI model

What is the function of each layer of the OSI model? The seven Open Systems Interconnection layers are the following.

Layer 7. The application layer

The application layer enables the user -- human or software -- to collaborate with the application or network whenever the user elects to read messages, transfer files or perform other network-related tasks. Web browsers and other internet-connected apps, such as Outlook and Skype, use Layer 7 application protocols.

Layer 6. The presentation layer

The presentation layer translates or formats data for the awarding layer based on the semantics or syntax the application accepts. This layer likewise handles the encryption and decryption that the awarding layer requires.

Layer v. The session layer

The session layer sets upwardly, coordinates and terminates conversations betwixt applications. Its services include authentication and reconnection after an interruption. This layer determines how long a system will wait for some other application to respond. Examples of session layer protocols include X.225 and Zone Data Protocol (Null).

Layer iv. The transport layer

The transport layer is responsible for transferring information across a network and provides error-checking mechanisms and data flow controls. It determines how much data to transport, where it gets sent and at what charge per unit. TCP within the TCP/IP suite is the best-known example of the ship layer. This is where the communications select TCP port numbers to categorize and organize data transmissions across a network.

Layer 3. The network layer

The master function of the network layer is to move data into and through other networks. Network layer protocols attain this by packaging data with correct network address data, selecting the appropriate network routes and forwarding the packaged data upward the stack to the transport layer. From a TCP/IP perspective, this is where IP addresses are practical for routing purposes.

Layer ii. The data-link layer

The data-link, or protocol layer, in a program handles moving data into and out of a concrete link in a network. This layer handles bug that occur as a event of fleck manual errors. Information technology ensures that the stride of the information menses doesn't overwhelm the sending and receiving devices. This layer also permits the transmission of information to Layer 3, the network layer, where information technology's addressed and routed.

The information-link layer tin be further divided into two sublayers. The higher layer, which is chosen logical link control (LLC), is responsible for multiplexing, flow control, acknowledgement and notifying upper layers if transmit/receive (TX/RX) errors occur.

The media access control sublayer is responsible for tracking data frames using MAC addresses of the sending and receiving hardware. It'south also responsible for organizing each frame, marking the starting and catastrophe bits and organizing timing regarding when each frame tin exist sent along the physical layer medium.

Layer 1. The concrete layer

The physical layer transports data using electrical, mechanical or procedural interfaces. This layer is responsible for sending reckoner bits from one device to some other along the network. It determines how concrete connections to the network are ready up and how bits are represented into predictable signals as they're transmitted either electrically, optically or via radio waves.

The vii layers of the OSI model

Cross-layer functions

Cantankerous-layer functions, or services that may affect more than one layer, include the following:

• security service telecommunications as defined past the International Telecommunications Spousal relationship Standardization Sector (ITU-T) X.800 recommendation;
• management functions that enable the configuration, instantiation, monitoring and terminating of the communications of two or more than entities;
• Multiprotocol Characterization Switching (MPLS), which operates at an OSI model layer that lies between the Layer 2 data-link layer and the Layer 3 network layer -- MPLS tin can carry a variety of traffic, including Ethernet frames and IP packets;
• Accost Resolution Protocol (ARP) translates IPv4 addresses (OSI Layer 3) into Ethernet MAC addresses (OSI Layer 2); and
• domain name system (DNS), which is an awarding layer service that's used to look up the IP accost of a domain proper noun.

Pros and cons of the OSI model

The OSI model has a number of advantages, including the post-obit:

• It's considered a standard model in computer networking.
• The model supports connectionless, also as connection-oriented, services. Users can take advantage of connectionless services when they demand faster data transmissions over the internet and the connectedness-oriented model when they're looking for reliability.
• Information technology has the flexibility to adapt to many protocols.
• The model is more adaptable and secure than having all services bundled in one layer.

The disadvantages of the OSI model include the following:

• Information technology doesn't define whatever particular protocol.
• The session layer, which is used for session management, and the presentation layer, which deals with user interaction, aren't every bit useful as other layers in the OSI model.
• Some services are duplicated at various layers, such as the transport and information-link layers.
• Layers can't work in parallel; each layer must await to receive data from the previous layer.

OSI model vs. TCP/IP model

The OSI reference model describes the functions of a telecommunications or networking arrangement, while TCP/IP is a suite of communication protocols used to interconnect network devices on the internet. TCP/IP and OSI are the most broadly used networking models for communication.

The OSI and TCP/IP models have similarities and differences. The main similarity is in their construction, as both use layers, although the OSI model consists of seven layers, while TCP/IP consists of merely four layers.

Some other similarity is that the upper layer for each model is the application layer, which performs the aforementioned tasks in each model but may vary according to the data each receives.

The functions performed in each model are also similar because each uses a network and transport layer to operate. The OSI and TCP/IP model are more often than not used to transmit information packets, although they each use unlike means and paths to reach their destinations.

Additional similarities between the OSI and TCP/IP models include the following:

• Both are logical models.
• Both define standards for networking.
• They each divide the network advice process in layers.
• Both provide frameworks for creating and implementing networking standards and devices.
• They enable ane manufacturer to make devices and network components that can coexist and work with the devices and components fabricated by other manufacturers.
• Both divide complex functions into simpler components.

Differences between the OSI and TCP/IP models include the following:

• OSI uses three layers -- application, presentation and session -- to define the functionality of upper layers, while TCP/IP uses only the application layer.
• OSI uses ii separate layers -- physical and data-link -- to define the functionality of the bottom layers, while TCP/IP uses but the link layer.
• OSI uses the network layer to define the routing standards and protocols, while TCP/IP uses the net layer.
